The Electra Electric Transporter

Electric Transporter

The Electra - Standard and Clean Line

The Electra conveyors are the most compact and maintenance-free transporters available today.  Quiet and clean, they consume just 5% of the energy that pneumatic units use.

* Quick and Easy Set-up (4 Bolts)

* Mechanical Speed Adjustment allows you to set The Electra for different applications. Depending on what needs to be sorted or separated, the operator is able to adjust the rate of motion for strength or speed allowing for complete customization of your operation.

* Internal Motion Sensor monitors production to ensure 100% productivity and eliminate costly downtime.

* Design a Custom Tray Configuration to suit your application.

Select: Inches Metric

Models
Max. Tray Weight Lbs.
Load Capacity with Tray Lbs.
Stroke Length In.
Sound Level (db-A)
Energy Consumption (kW)
Request A Quote
ET-10
8.8
22
0.78
60
0,05
Request Quote
ET-10CL
8.8
22
0.78
60
0.05
Request Quote
ET-20
17.5
44
0.78
60
0.07
Request Quote
ET-20CL
17.5
44
0.78
60
0.07
Request Quote
ET-40
35
88
0.78
60
0.15
Request Quote
ET-40CL
35
88
0.78
60
0.15
Request Quote
Models
Max. Tray Weight Kg
Load Capacity with Tray Kg
Stroke Length mm
Sound Level (db-A)
Energy Consumption (kW)
Request A Quote
ET-10
4
10
20
60
0,05
Request Quote
ET-10CL
4
10
20
60
0.05
Request Quote
ET-20
8
20
20
60
0.07
Request Quote
ET-20CL
8
20
20
60
0.07
Request Quote
ET-40
16
40
20
60
0.15
Request Quote
ET-40CL
16
40
20
60
0.15
Request Quote

No Dimensions Found

No Documents Found
